Features
- Ruggedized sealing system for Fiber-to-the-Antenna and industrial applications
- Open bulkhead for easy access to SFP
- Positive mechanical feedback to operator when fully mated
- MPO/MTP interface
- Duplex LC interface
- Robust bayonet locking for easy, fast and secure mating
- Waterproof, dust proof and corrosion resistant
Specifications
| Mating mechanism | bayonet style locking | |
| Housing material | high performance plastic | |
| Technology |
MT Ferrules with full PPS thermoplastic LC with full ceramic ferrules |
|
| Mechanical performance | tensile load static side load |
150 N 30 N |
| Operating temperature | −40 to +70 °C | |
| Mating durability | IEC 61300-2-2 | 100 cycles |
| Ingress protection (mated) | IEC 60529 | IP67 |
| Vibration | IEC 61300-2-1 | passed 10 to 500 Hz/10g |
| Performance standards | IEC 61753-1 cat. E Telcordia GR 3120 |
compliant compliant |
Optical performance
| Insertion loss(MPO/MTP) | single-mode single-mode Low Loss multimode multimode Low Loss |
≦ 0.75 dB ≦ 0.35 dB ≦ 0.5 dB ≦ 0.35 dB |
| Return loss(MPO/MTP) | single-mode multimode |
APC≥ 60 dB PC≥ 20 dB |
| Insertion loss(LC) | single-mode single-mode Low Loss multimode multimode Low Loss |
≦ 0.2 dB ≦ 0.15 dB ≦ 0.3 dB ≦ 0.15 dB |
| Return loss(LC) | single-mode |
UPC ≥ 55 dB,APC ≥ 60 dB |
